cheap Portable open channel swirl Electromagnetic Velocity Flow
Meter
Production description cheap Portable open channel swirl
Electromagnetic Velocity Flow Meter
The KL SERIES series of electromagnetic velocity meter is portable
instrument flow designed for the flow velocity/rate measurement.
It’s professional for agricultural irrigation, hydrologic
monitoring, rivers flow monitoring, municipal water. The low-power
design and full digital signal processing technology make
measurement more stable and reliable. The range is wide and high
accuracy. It widely applies to the measurement of flow velocity and
rate for industry requires moving frequently such as agricultural
irrigation, hydrology and water conservancy.
Specification cheap Portable open channel swirl Electromagnetic
Velocity Flow Meter
| KL SERIES Portable Electromagnetic Velocity Meter |
| Range: | Velocity 0.005m/s~10m/s(resolution 5mm/s) |
| Accuracy: | ± 1.0%FR+0.005m/s |
| Acquisition time: | Auto 10S~900S adjustable, hand control time |
| Power | 1.5V*5pcs NO.5 battery |
| Display | LCD big screen back light display, flow(Ⅱ-model), accumulative
total(Ⅱ-model), level(Ⅱ-model), flow direction, electric quantity,
alarm information, running time, running status |
| Physical interface: | RS485(optional) |
| Conductivity: | >20µs/cm |
| Medium temperature: | 0C~60C |
| Ambient temperature: | - 10C~50C |
| Display digits: | 3 digits(X.XXX) |
| Size: | 204*100*35mm(Display); |
| Size: | Φ32×460(mm)(Sensor) |
| Measuring rod: | Normal 500mm×Sections (500mm×optional sections) or lifting
accessories. |
Production Features cheap Portable open channel swirl
Electromagnetic Velocity Flow Meter
1,No movable parts, no winding. No choked flow, no maintenance,
avoid troubles of
other calibration and testing;
2,Micro-power design can last 80 hours when replace the
battery(Ⅱ-model,optional for
level sensor);
2,LCD big screen back light display shows measuring data clearly in
sunlight and night； The instrument interface display velocity
,flow(Ⅱ-model), accumulative
total(Ⅱ-model), level(Ⅱ-model), flow direction, electric quantity,
alarm information, running time, running status；
4,Simple operation, wading rod measurement, wire measurement and
sailing
measurement are available choice.
5,Auto power shut off.
Applications cheap Portable open channel swirl Electromagnetic
Velocity Flow Meter
Product Complete set cheap Portable open channel swirl
Electromagnetic Velocity Flow Meter
1 KL SERIES Portable velocity display 1set
2 Velocity sensor 1set
3 Velocity meter tail 1set
4 Steel measure tape 1pc
5 Allen wrench 3pc
6 Measuring insert rod(Order length) 1set
7 Measuring steel wire(Order length) 1pc
Random documents
1 Operation instruction 1pc
2 Product certificate 1pc
3 Package 1pc
4 Feedback 1pc
