Dry Well Temperature Calibrator Calibration Temperature Dry Block
Temperature Calibrator
Description Dry Well Temperature Calibrator Calibration Temperature Dry Block
Temperature Calibrator
The portable dry body temperature calibration furnace adopts a
highly stable temperature controller, and the soaking block adopts
an alloy material with good thermal conductivity. In terms of
technology, it is synchronized with advanced technologies at home
and abroad, and it is at the leading level in terms of insertion
depth, horizontal temperature field, and vertical temperature
field. Used within the desired temperature range, it can be easily
set up and produced precisely to the desired temperature. It has
the characteristics of small size, fast heating, stable temperature
control, and no pollution. It can check the temperature sensor and
the instrument as a whole, so it is very suitable for industrial
use.
Specification Dry Well Temperature Calibrator Calibration Temperature Dry Block
Temperature Calibrator
| Model No. | W150 | W600 | W1000 |
| Temperature Range | -20℃ ~ 150℃ | 50℃ ~ 650℃ | 300℃ ~ 1200℃ |
| Heat Source | Semiconductor refrigeration | electro-thermal | electro-thermal |
| Accuracy | 0.2% | 0.2% | 0.2% |
| Stability | ±0.04℃ | ±0.1℃ | ±0.1℃ |
| Resolution | 0.1℃ | 0.1℃ | 0.1℃ |
| Horizontal Temperature Field | ≤±0.25℃ | ≤±0.1℃ | ≤±0.3℃ |
| Vertical Temperature Field | From the bottom of the well 30mm≤0.5℃ | From the bottom of the well30mm≤0.5℃ | From the bottom of the well30mm≤±0.5℃ |
| Well Depth | 150mm | 200mm | 200mm |
| Wellhead Size | 40mm | 40mm | 40mm |
| Hole Size | φ9×6 | φ9×4 | φ9×6 |
| Box Size | 390x185x320mm | 330x165x320mm | 378x182x320mm |
| Power | 400W | 400W | 500W |
| Power Supply | 220V ~ 50Hz | 220V ~ 50Hz | 220V ~ 50Hz |
| Weight | 20kg | 20kg | 20kg |
Application Dry Well Temperature Calibrator Calibration Temperature
Dry Block Temperature Calibrator
Used in the required temperature range, it is easy to set and
accurately produce the required temperature.It has the
characteristic of small volume, fast heating, stable temperature
control, no pollution, etc.The temperature sensor and instrument
can be integrally calibrated, so it is easy to carry, easy to use,
easy to fast and reliable temperature calibration. It is widely
used in machinery, chemical, food, pharmaceutical and other
industries.
